05 toyota tundra headlight adjustment. The headlamp aim moves up when turning the aiming screw clockwise and moves down when turning the aiming screw counterclockwise. Use the mark as a reference point for your headlights. Unplug the two harnesses that hook into the headlight if needed and it is ready to be removed the car.

Red arrow indicates the side-to-side adjuster and his finger. Dont touch the upper adjustment screws that are for horizontal adjustment - they have a protective black plastic cap on them. The procedure listed below is for the LH side.

My 2011 Odyssee lights show almost exactly what your new Tundra lights show. The attached document below may help in adjusting your lights. They are the galvanized 8mm hex heads with the weird notched washer.

I had a drivers side headlight that pointed way off to the left and I took it to the dealer and that is where they said the adjuster was. The one circled in red should be your side to side adjustment. Adjuster Locations and Effects Vertical Adjustment.

Ive tried turning what seems to be the adjustment gears on the upper left and lower right of the headlight assembly with no success. Adjust the vertical headlight aim into the specified range by turning aiming screw A with a screwdriver. But i think counter will bring it down.

Adjust the vertical headlight aim into the specified range by turning aiming screw A with a screwdriver. You want the low beam to be within two-inches of the mark which centers the high beam directly on the mark. Mark location of the light with a piece of tape or something then turn it one way till you notice it moving up or down if its moving the wrong direction go back the other way.
